High Efficency Gel Lead Acid Battery M8 Terminal For Off Grid Power System

Brand Name : Champion

Model Number : 3FM225G

Certification : CE ; UL

Place of Origin : China

MOQ : Negotiation

Price : negotiation

Payment Terms : 30% in advance, T/T

Supply Ability : 300,000 pieces per month

Delivery Time : 25 days

Packaging Details : Carton box

Model Name : 3FM225G

Size : 321*176*226 mm

Voltage : 6V

Terminal : M8

Capacity : 225AH

Color : Black

Weight : 31kg

Application : GOLF CART;Wheelchairs;Electric Power Vehicles

Contact Now

High Efficency Gel Lead Acid Battery M8 Terminal For Off Grid Power System



Gel Lead Acid Battery Description:



Champion 6V 225AH Deep cycle gel battery is very suitable for off grid power system, wide used in Africa solar projects,and be accepted with high praise for many years,due to Champion's good reputation of battery manufacturing for past 16 years,and with only 0.1% failure rate, 10 times less than average from China's competitors.



Gel Lead Acid Battery data :



3FM36G 6 36 162 88 164 170 F2 5 5.5
3FM42G 6 42 6.1
3FM100G 6 100 194 170 205 210 M8 4 15.5
3FM150G 6 150 260 180 245 250 M8 5 23
3FM180G 6 180 307 169 220 225 M8 5 27
3FM200G 6 200 M8 29
3FM200G 6 200 321 176 226 229 M8 4 29.5
3FM225G 6 225 321 176 226 229 M6 5 31
3FM300G 6 300 295 178 345 348 M8 5 47



Gel Lead Acid Battery Applications:



1) Golf Cars, Wheelchairs& Electric Power Vehicles
2) Power Tools, Lawn Mowers & Vacuum Cleaners
3) Electric Toys & Recreation Equipments





Gel Lead Acid Battery Specifications:





Place of Origin:
Guangdong, China (Mainland)
 Brand Name:
Champion
Type:
Deep cycle GEL Battery
 Nominal Voltage:
6V
Nominal Capacity:
225AH
 name:
Battery 6v225ah for golf cart,Deep cycle battery for motive power
sample:
available
 service:
OEM
printing color:
white
 warranty time:
2 years



Capacity                                   77°F(25°C) 20 hours rate(10.4A 5.4V) 233Ah
10 hours rate(20A 5.4V) 225Ah
5 hours rate(35A 5.25V) 200Ah
1 hour rate(130A 4.8V) 155Ah
Internal Resistance Full charged battery 77°F(25°C):4mΩ
Capacity affected by Temperature               (10 hour rate) 104°F(40°C) 102%
77°F(25°C) 100%
32°F(10°C) 85%
5°F(-15°C) 65%
Self-Discharge             68°F(20°C) Capacity after 3 month storage 90%
Capacity after 6 month storage 80%
Capacity after 12 month storage 60%
Max discharge current77°F(25°C):1000A(5S)
Charge                           (Constant Voltage) Float:6.8 to 6.9V/77°F/(25°C)
Cycle:7.25 to 7.45V/77°F/(25°C)
Max Current:50A



Competitive Advantage:



  •  Excellent safety performance.
  •  Good discharging performance.
  •  Good impact-proof performance.
  •  Good resistance to over discharge.
  •  Good resistance to overcharge.
  •  Good resistance to high current.
